24MVA 138000D - 21600Y Howard Industries LTC Substation Transformer

One (1) 24/32/40 MVA Kuhlman Substation Transformer
3 ph, 60 Hz, ONAN/ONAF/ONAF, 55/65 Deg C Rise,
All Copper Windings, 10.15% Impedance, Liquid Level Gauge,
Liquid Temp Gauge, Vacuum Pressure Gauge, Pressure Release Valve,
Drain & Sample Valve, Top-Top Bushings

HV: 138000 Deta BIL: 650 KV
LV: 21600 Wye BIL: 150 KV
Taps: 144900-141450-138000-134550-131500
LV Taps: +/- 0.625% in 32 steps

CORE & COIL WEIGHT lb
TANK & FITTINGS WEIGHT lb
FLUID WEIGHT lb
FLUID GALLONS gal (US)
TOTAL WEIGHT 199280 lb

Dimensions: Coming Soon
