1000 kVA 13200D - 480D Dry Type Transformer

KVA: 1000/1333 KVA
Manufacturer: The Electric Service Co
Primary - First: 13200 V
Primary - First Vector: Delta
Secondary - First: 480 V
Secondary - First Vector: Delta
Type: Dry Type
Phase: 3
HERTZ: 60
CLASS: AA/FA
TEMPERATURE RISE: 150 °C
IMPEDANCE: 6.3
Primary - First BIL: 95 kV
TAPS: 14400-14100-13800-13530-13200-12870-12470-12180-11850
Secondary - First BIL: 10 kV
Cabinet Type: Outdoor
Winding Conductor: Copper
TEMPERATURE GAUGE: Yes
CORE & COIL WEIGHT: 6500 lb
TOTAL WEIGHT: 8500 lb
