7500 KVA, 68800D- 13090Y/7550 ABB Substation Transformer, Mineral Oil

KVA: 7500/9375 KVA
Manufacturer: ABB
Phase: Three
HERTZ: 60
CLASS: OA/FA
TEMPERATURE RISE: 65 °C
IMPEDANCE: 7.97
Primary - First: 68800 V
Primary - First Vector: Delta
Primary - First BIL: 350 kV
Secondary - First: 13090 V
Secondary - First Vector: Wye
Secondary - First BIL: 110 kV
HV BUSHING LOCATION: Top
LV BUSHING LOCATION: Top
STANDARD TAPS: 72240-70520-68800-67080-65300
CORE & COIL WEIGHT: 22631 lb
TANK & FITTINGS WEIGHT: 10767 lb
FLUID WEIGHT: 11707 lb
FLUID GALLONS: 1561 gal (US)
TOTAL WEIGHT: 45105 lb
FLUID TYPE: Mineral Oil
LIQUID LEVEL GAUGE: Yes
DRAIN & TEST VALVE: Yes
TEMPERATURE WINDING GAUGE: Yes
