25/33.25/41.5 MVA Weg Transformer, 34500 Delta, 13800 Wye, LTC

25/33.25/41.5 MVA Weg Transformer, 3 Phase, 60hz, Class ONAN/ONAF/ONAF,
65 Deg C Rise, Side-Side bushing locations, Tap changer, Liquid Level Gauge,
Liquid Temp Gauge, Winding Temp Gauge, Conservator Tank, 6.97%
All Copper Windings, 12x CTs 2000:5, drain and sample valve, Partial ATC's

HV: 34500 Delta 200kV BIL
LV: 13800 Wye 110kV BIL

32 Taps, 16 Taps above, 16 taps below

Total Weight: 128240lbs
Core & Coils: 55556lbs
Tank & Fittings: 39917lbs
Liquid: 32767lbs (4412 gal)
