2500/2800 KVA, Pri 12470 Y, Sec 480 Y, Silicone, Live Front, Radial Feed
Silicone Filled Transformer
Product Number:
045520
Full Product Description
One (1) 2500/2800 KVA Westinghouse Silicone Pad-mount Transformer, Live
Front, Radial Feed, OA Class, 5.76% Imp, 55/65 Deg C Rise, 60hz,
All AL windings, Liquid Level Gauge, Tap Changer, Vacuum Pressure
Gauge, Drain and Sample Valve
HV: 12470/7200Y BIL: 95kV
LV: 480Y/277 BIL: 30kV
TAPS: 13090-12780-12470-12160-11850
DIMMS: 95"H x 133"W x 97"D
Front, Radial Feed, OA Class, 5.76% Imp, 55/65 Deg C Rise, 60hz,
All AL windings, Liquid Level Gauge, Tap Changer, Vacuum Pressure
Gauge, Drain and Sample Valve
HV: 12470/7200Y BIL: 95kV
LV: 480Y/277 BIL: 30kV
TAPS: 13090-12780-12470-12160-11850
DIMMS: 95"H x 133"W x 97"D
