225 KVA, Pri 4160 D, Sec 480 Y, LF/RF SQUARE D PADMOUNT TRANSFORMER

T-6176

ONE (1) 225 KVA SQUARE D PADMOUNT TRANSFORMER
3 PH, 60 HZ, RTEMP LIQUID, 3.67% IMPEDANCE,
65 DEG C RISE, CLASS OA, LIVE FRONT, RADIAL FEED,
BAYONET FUSES, AL WINDINGS, DRAIN & SAMPLE VALVE,
LIQUID TEMP GAUGE, LIQUID LEVEL GAUGE, PRESSURE
RELEASE VALVE,

HV: 4160 DELTA BIL: 60 KV
LV: 480Y/277 BIL: 30 KV
TAPS: 4308-4264-4160-4056-3952

TOTAL WEIGHT: 3610 LBS
CORE & COILS: 1170 LBS
TANK & FITT.: 1090 LBS
LIQUID-RTEMP: 1350 LBS (180 GAL)

DIMENSIONS: COMING SOON
