3750/4200 KVA, 12470 D, 4160Y/2400, 2002, PENNSYLVANIA TRANSFORMER, COPPER:2
SUBSTATION TRANSFORMER
Product Number:
044423
Full Product Description
<
TWO (2) 3750/4200KVA PENNSYLVANIA TRANSFORMER TECHNOLOGY SUBSTATION<
TRANSFORMERS, 3 PHASE, 60 HERTZ, CLASS OA, 55/65 DEG. C RISE,<
8.4% IMPEDENCE, COPPER WINDINGS, <<
<
HIGH VOLTAGE: 12470 DELTA BIL: 110 KV<
LOW VOLTAGE: 4160Y/2400 BIL: 60 KV<
TAPS: 13090-12780-12470-12160-11850<
<
TOTAL WEIGHT: 26,250 LBS.<
CORE & COIL: 11,498 LBS.<
TANK & FIT: 7,745 LBS.<
TWO (2) 3750/4200KVA PENNSYLVANIA TRANSFORMER TECHNOLOGY SUBSTATION<
TRANSFORMERS, 3 PHASE, 60 HERTZ, CLASS OA, 55/65 DEG. C RISE,<
8.4% IMPEDENCE, COPPER WINDINGS, <<
<
HIGH VOLTAGE: 12470 DELTA BIL: 110 KV<
LOW VOLTAGE: 4160Y/2400 BIL: 60 KV<
TAPS: 13090-12780-12470-12160-11850<
<
TOTAL WEIGHT: 26,250 LBS.<
CORE & COIL: 11,498 LBS.<
TANK & FIT: 7,745 LBS.<
