1000 KVA, Pri 13200 D, Sec 208Y/120, 2004, ABB, LIVE FRONT, RADIAL FEED:1
PADMOUNT TRANSFORMER
Product Number:
044250
Full Product Description
T-5954:
ONE (1) 1000 KVA ABB COMPARTMENTALIZED PADMOUNT TRANSFORMER, 3 PHASE,
60 HERTZ, CLASS OA, 65 DEG. C RISE, 5.52% IMPEDANCE, LIVE FRONT,
RADIAL FEED, LIQUID TEMPERATURE GAUGE, LIQUID LEVEL GAUGE, VACUUM
PRESSURE GAUGE, DRAIN & SAMPLE VALVE, MFG. 2004, S/N 704J978065
HIGH VOLTAGE: 13200 DELTA BIL: 95 KV
LOW VOLTAGE: 208Y/120 BIL: 30 KV
TAPS: 14400-13800-13200-12870-12470-12000-11700
TOTAL WEIGHT: 10,371 LBS.
CORE & COILS: 2,513 LBS.
TANK & FIT.: 3,163 LBS.
OIL: 4,695 LBS. (396 GALS.)
DIMENSIONS: 75.5"H X 65"W X 80.5"D Low Voltage Bushing (X0, X2): 46.5" (X1, X3): 53.5" High Voltage Bushings: 37.5"
ONE (1) 1000 KVA ABB COMPARTMENTALIZED PADMOUNT TRANSFORMER, 3 PHASE,
60 HERTZ, CLASS OA, 65 DEG. C RISE, 5.52% IMPEDANCE, LIVE FRONT,
RADIAL FEED, LIQUID TEMPERATURE GAUGE, LIQUID LEVEL GAUGE, VACUUM
PRESSURE GAUGE, DRAIN & SAMPLE VALVE, MFG. 2004, S/N 704J978065
HIGH VOLTAGE: 13200 DELTA BIL: 95 KV
LOW VOLTAGE: 208Y/120 BIL: 30 KV
TAPS: 14400-13800-13200-12870-12470-12000-11700
TOTAL WEIGHT: 10,371 LBS.
CORE & COILS: 2,513 LBS.
TANK & FIT.: 3,163 LBS.
OIL: 4,695 LBS. (396 GALS.)
DIMENSIONS: 75.5"H X 65"W X 80.5"D Low Voltage Bushing (X0, X2): 46.5" (X1, X3): 53.5" High Voltage Bushings: 37.5"
