600 Amp, POWERCON, No. PIF, 23000 V., 3 SECTION, OUTDOOR, LINE-UP
SWITCH LINE-UP
Product Number:
042731
Full Product Description
CB-19012 & ABC:
ONE (1) POWERCON OUTDOOR CONSISTING OF THREE (3) SECTIONS
A - ONE (1) 600 AMP POWERCON SWITCHGEAR CABINET
TYPE PIF
MODEL 577-09
ONE (1) 600 AMP SWITCH
3 POLE
23 KV
25.8 KV MAX.
125 KV BIL
40 KA SHORT CIRCUIT
40 KA FAULT CLOSE
B - METERING SECTION
ABB TYPE VOZZ-15 PT
24000/24000Y
150 KV BIL
120 V SECONDARY
200:1 RATIO
3000 VA THERMAL RATING
LINE-TO-GROUND
13856 PRIMARY VOLTS
69.28 SECONDARY
0.3 ACCY
2 X GE CURRENT LIMITING FUSES
TYPE EJO-1C
3 AMP
25.5 KV
1 X 5 AMP ABB HCB PILOT WIRE RELAY
STYLE 292B930A10Z
C - 3 X S&C 300 AMP FUSES
25/27 KV
SM-5S HOLDER WITH 150 AMP REFILLS
