10000/14000 KVA, Pri 24000 D, Sec 12470Y/7200, 2012, COPPER WINDINGS

ONE (1) 10/11.2/12.5/14 MVA T & R ELECTRIC SUBSTATION TRANSFORMER, 3 PHASE,
60 HERTZ, CLASS ONAN/ONAN/ONAF/ONAF, 55/65 DEGREE C RISE, 7.0%
IMPEDANCE, COPPER WINDINGS, LIQUID LEVEL GAUGE, OIL TEMPERATURE GAUGE,
VACUUM PRESSURE GAUGE, NEUTRAL GROUNDING RESISTOR, TOP X TOP BUSHINGS,
MFG. 2012

HIGH VOLTAGE: 24000 DELTA BIL: 150 KV
LOW VOLTAGE: 12470Y/7200 BIL: 110 KV
TAPS: 26000-25000-24000-23000-22000

TOTAL WEIGHT: 53,940 LBS.
CORE & COILS: 25,480 LBS.
TANK & FIT.: 12,800 LBS.
OIL: 15,660 LBS. (2,102 GALS.)
