225 KVA, Pri 4160 D, Sec 208Y/120, WESTINGHOUSE, DEAD FRONT, RADIAL FEED:1

JVT-3727:

ONE (1) 225 KVA WESTINGHOUSE COMPARTMENTALIZED PADMOUNT TRANSFORMER, 3 PHASE,
60 HERTZ, CLASS OA, 65 DEG. C RISE, 5.1% IMPEDANCE, DEAD FRONT, RADIAL
FEED, LIQUID TEMPERATURE GAUGE, LIQUID LEVEL GAUGE, DRAIN & SAMPLE
VALVE, HV COPPER, LV ALUMINUM, S/N 3013154218

HIGH VOLTAGE: 4160 DELTA
LOW VOLTAGE: 208Y/120
TAPS: 4370-4265-4160-4055-3950

TOTAL WEIGHT: 3,215 LBS.
DIMENSIONS: 47"H X 46 1/2"W X 38 1/2"D
