ABB PBA BUSHING POTENTIAL DEVICE, 300 WATT MAX, 289000 V, PRI, 115/66.4 SEC.:1
BUSHING POTENTIAL DEVICE
Product Number:
041884
Full Product Description
CPT-162A:
ONE (1) ABB BUSHING POTENTIAL DEVICE
TYPE PBA
300 WATT MAX. OUTPUT
75 WATT AUXILIARY WINDING
289 KV LINE TO GROUND
500 KV BIL
ACCURACY CLASS A
60 HERTZ
S2-S3 66.4 & S1-S3 115 V SECONDARY VOLTAGES ON SAME WINDING
Z2-Z3 66.4 & Z1-Z3 115 V SECONDARY VOLTAGES ON AUX. SEPARATE WINDING
3D70617 WIRING DIAGRAM
INST. BOOK 33-357-7
C3=7000
500 LBS.
