2000 Amp, GENERAL ELECTRIC, WPS-20, 480 V., 240 VAC CLOSE & TRIP, DRAW-OUT:1
AIR BREAKER
Product Number:
041842
Full Product Description
CB-18711:
ONE (1) 2000 AMP GENERAL ELECTRIC WAVEPRO AIR CIRCUIT BREAKER
TYPE WPS-32
635/508/254 VOLT
65 KA TRIP INST. & W/O INST.
65 KA SHORT TIME
50/60 HERTZ
3 POLES
CAT. #WE1JADNT3XBAXFX
INST. BOOK - DEH-134
OUTLINE - 10056546SH1
240 VAC CLOSE & TRIP
DRAW-OUT
MICRO-VERSA TRIP PLUS TRIP UNIT
S/N RMS9D002639
2000 AMP RATING PLUG
2000 AMP SENSOR
TYPE K220LSIGZ2R
CONNECTION DIAGRAM - 10057403-P1
RENEWAL PARTS BULLETIN DEF-004
S/N P140006434-02-01
BELL ALARM
ONE (1) 2000 AMP GENERAL ELECTRIC WAVEPRO AIR CIRCUIT BREAKER
TYPE WPS-32
635/508/254 VOLT
65 KA TRIP INST. & W/O INST.
65 KA SHORT TIME
50/60 HERTZ
3 POLES
CAT. #WE1JADNT3XBAXFX
INST. BOOK - DEH-134
OUTLINE - 10056546SH1
240 VAC CLOSE & TRIP
DRAW-OUT
MICRO-VERSA TRIP PLUS TRIP UNIT
S/N RMS9D002639
2000 AMP RATING PLUG
2000 AMP SENSOR
TYPE K220LSIGZ2R
CONNECTION DIAGRAM - 10057403-P1
RENEWAL PARTS BULLETIN DEF-004
S/N P140006434-02-01
BELL ALARM
