225000 KVA, Pri 138000 Y, Sec 17550 D, 1991, PEEBLES, COPPER:1

ONE (1) 225 MVA PEEBLES GENERATOR STEP-UP TRANSFORMER, 3 PHASE, 60 HERTZ,
CLASS FOA, 65 DEGREE C RISE, 13.85% IMPEDANCE, COPPER WINDINGS

HIGH VOLTAGE: 138000 WYE BIL: 650 KV
LOW VOLTAGE: 17550 DELTA BIL: 150 KV
TAPS: 144900-141450-138000-134550-131100

TOTAL WEIGHT: 397,000 LBS.
CORE & COILS: 71,900 LBS.
TANK & FIT.: 69,400 LBS.
OIL: 76,250 LBS. (10,500 GALS.)
SHIPPING: 304,300 LBS.
