1000/1120 KVA, 12470D, Sec 480Y/277, 1991, SQUARE D, SILICONE SUBSTATION
SUBSTATION TRANSFORMER
Product Number:
041595
Full Product Description
STOCK #T-5794
ONE (1) 1000/1120 KVA SQUARE D SUBSTATION TRANSFORMER, SILICONE, 3 PHASE
60 HERTZ, 5.90% IMPEDANCE, CLASS OA/FFA, 55/65 DEG. C RISE, ALUMINUM
WINDINGS, SIDE MOUNTED BUSHINGS, S/N 910157-B1
HV: 12470 DELTA
LV: 480Y/277
TAPS: 13093-12781-12470-12158-11846
TOTAL WEIGHT: 7190 LBS.
CORE & COILS: 2920 LBS.
TANK & FITTINGS: 1990 LBS.
GAL. (285) 2280 LBS.
DIMENSIONS: 67"H X 73.5"W X 68.5D
FLANGE TO FLANGE: 38"W
HV FULL LENGTH ATC CLOSED CABINET
ATC DIMENSIONS: 38"W X 18.25"D X 67'H
OC HV BUSHINGS 55.5
OC LV BUSHINGS 55"
BUSHING LOCATION:
HV: ANSI 1
LV: ANSI 4
ONE (1) 1000/1120 KVA SQUARE D SUBSTATION TRANSFORMER, SILICONE, 3 PHASE
60 HERTZ, 5.90% IMPEDANCE, CLASS OA/FFA, 55/65 DEG. C RISE, ALUMINUM
WINDINGS, SIDE MOUNTED BUSHINGS, S/N 910157-B1
HV: 12470 DELTA
LV: 480Y/277
TAPS: 13093-12781-12470-12158-11846
TOTAL WEIGHT: 7190 LBS.
CORE & COILS: 2920 LBS.
TANK & FITTINGS: 1990 LBS.
GAL. (285) 2280 LBS.
DIMENSIONS: 67"H X 73.5"W X 68.5D
FLANGE TO FLANGE: 38"W
HV FULL LENGTH ATC CLOSED CABINET
ATC DIMENSIONS: 38"W X 18.25"D X 67'H
OC HV BUSHINGS 55.5
OC LV BUSHINGS 55"
BUSHING LOCATION:
HV: ANSI 1
LV: ANSI 4
