2000 Amp, MITSUBISHI, 70-SFMT-40E, 72.5 KV, 2007, BM-1 MECH., 125 VDC C & T
SF6 CIRCUIT BREAKER
Product Number:
041558
Full Product Description
CB-18601:
ONE (1) 2000 AMP MITSUBISHI SF6 CIRCUIT BREAKER
TYPE 70-SFMT-40E
72.5 KV MAXIMUM VOLTAGE
60 HERTZ
1.0 RANGE FACTOR K
40 KA SHORT CIRCUIT
3 CYCLE INTERRUPT
350 KV BIL
125 VDC CLOSE & TRIP
125 VDC MOTOR
240 VAC HEATER
71 PSIG NORMAL PRESSURE
64 PSIG ALARM PRESSURE
57 PSIG MINIMUM PRESSURE
BM-1 SPRING CHARGED MECHANISM
6 X 1200:5 MRCT'S
6 X 2000:5 MRCT'S
4600 LBS.
52 LB.S OF GAS
SCHEMATIC DIAGRAM D32086
WIRING DIAGRAM D302087
INST. BOOK PEB0131
PARTS LIST PEB0132
ONE (1) 2000 AMP MITSUBISHI SF6 CIRCUIT BREAKER
TYPE 70-SFMT-40E
72.5 KV MAXIMUM VOLTAGE
60 HERTZ
1.0 RANGE FACTOR K
40 KA SHORT CIRCUIT
3 CYCLE INTERRUPT
350 KV BIL
125 VDC CLOSE & TRIP
125 VDC MOTOR
240 VAC HEATER
71 PSIG NORMAL PRESSURE
64 PSIG ALARM PRESSURE
57 PSIG MINIMUM PRESSURE
BM-1 SPRING CHARGED MECHANISM
6 X 1200:5 MRCT'S
6 X 2000:5 MRCT'S
4600 LBS.
52 LB.S OF GAS
SCHEMATIC DIAGRAM D32086
WIRING DIAGRAM D302087
INST. BOOK PEB0131
PARTS LIST PEB0132
