7500/10500 KVA, Pri 33000 D, Sec 13200Y/7620, ABB, COPPER
SUBSTATION TRANSFORMER
Product Number:
041323
Full Product Description
JVT-3677:
ONE (1) 7500/8400/9375/10500 KVA ABB SUBSTATION TRANSFORMER, TYPE RSL,
3 PHASE, 60 HERTZ, CLASS OA/FA, 55/65 DEG. C RISE, 6.43% IMPEDANCE,
COPPER WINDINGS, Full ATC HV and LV
HIGH VOLTAGE: 33000 DELTA BIL: 200 KV
LOW VOLTAGE: 13200Y/7620 BIL: 110 KV
TAPS: 34650-33830-33000-32180-31350
TOTAL WEIGHT: 43,882 LBS.
CORE & COILS: 22,848 LBS.
TANK & FIT.: 9.724 LBS.
OIL: 11,310 LBS. (1,465 GALS.)
DIMENSIONS: 135"H X 119"W X 165"L
SHIPPING: 135"H X 119"W X 124"L
