750 KVA, Pri 4160 D, Sec 208Y/120, 1994, GENERAL ELECTRIC, DEAD/LOOP, FUSED:1
PADMOUNT TRANSFORMER
Product Number:
040929
Full Product Description
JVT-3624
ONE (1) 750 KVA GENERAL ELECTRIC COMPARTMENTALIZED PADMOUNT TRANSFORMER,
3 PHASE, 60 HERTZ, CLASS OA, 65 DEG. C RISE, 5.65% IMPEDANCE, DEAD
FRONT, LOOP FEED, HV COPPER, LV ALUMINUM, DRAIN & SAMPLE VALVE, LIQUID
TEMPERATURE GAUGE, LIQUID LEVEL GAUGE, PRESSURE VACUUM GAUGE, CURRENT
LIMITING FUSES, EXTERNAL GROUND STRAP, A/B SWITCH, MFG. 1994, S/N
Q241411-TOJ
HIGH VOLTAGE: 4160 DELTA BIL: 60 KV
LOW VOLTAGE: 208Y/120 BIL: 30 KV
TAPS: 4370-4260-4160-4060-3950
TOTAL WEIGHT: 7,881 LBS.
CORE & COILS: 1,767 LBS.
TANK & FIT.: 3,728 LBS.
OIL: 2,386 LBS. (318 GALS.)
DIMS: 77"H x 71"W x 74"D
