6.5/20 MVA, Pri 69000DX115000D, Sec 34500Y/19920X13200Y/7620, DELTA STAR, MOBILE

T-5761:

ONE (1) 6500/12000/16000/20000 KVA DELTA STAR MOBILE SUBSTATION TRANSFORMER,
3 PHASE, 60 HERTZ, CLASS OA/FA/FOA/FOA, 55/65 DEG. C RISE, 3 X HV
MRCT'S, 7 X LV MRCT'S, HV ALUMINUM, LV COPPER, HV ANSI 2, LV ANSI 4,
69 KV 10.95% IMPEDANCE, 115 KV 10.11% IMPEDANCE, S/N Y290045

HIGH VOLTAGE: 69000 D X 115000 D BIL: 450 KV
LOW VOLTAGE: 34500Y/19920 X 13200Y/7620 BIL: 200 KV
HV TAPS: 120750-117875-115000-112125-109250
HV TAPS: 71875-70438-69000-67563-66125

TOTAL WEIGHT: 65,500 LBS.
CORE & COILS: 20,000 LBS.
TANK & FIT.: 17,380 LBS.
OIL: 28,120 LBS. (3,800 GALS.)
SHIPPING: 133"H X 121"W X 242"L
