1600 Amp, ALSTOM, DT1-72.5 F1, 69 KV, 125 VDC CLOSE & TRIP, CRR4-5 MECH.
SF6 CIRCUIT BREAKER
Product Number:
040817
Full Product Description
CB-18327:
ONE (1) 1600 AMP ALSTOM SF6 CIRCUIT BREAKER
TYPE DT1-72.5 F1
72.5 KV
40 KA SHORT CIRCUIT
350 KV BIL
3 CYCLE INTERRUPT
RATED K FACTOR 1
60 HERTZ
98.6 PSIG OPERATING PRESSURE
48 LBS. OF GAS
CRR4-5 SPRING CHARGED MECHANISM
-30 DEG. C TO +40 DEG. C TEMPERATURE RANGE
125 VDC CLOSE & TRIP
120 VAC MOTOR
WIRING DIAGRAM DT09CO724
INSTRUCTION MANUAL DT0P-IM
12 X 2000:5 MRCT'S C800
CAPACITANCE CURRENT SWITCHING INFO:
RATED OVER VOLTAGE TRANSIENT FACTOR: 2.0
RATED OPEN-WIRE LINE CHARGING CURRENT: 100 A
RATED ISOLATED SHUNT CAPACITOR BANK CURRENT: 630 A
RATED BACK-TO-BACK SHUNT CAPACITOR BANK CURRENT: 630 A
RATED TRANSIENT INRUSH CURRENT PEAK: 25 KA
RATED TRANSIENT INRUSH CURRENT FREQUENCY: 3360 HZ
RATED OUT OF PHASE SWITCHING CURRENT: 10 KA
5328 LBS.
1313"H X 103.9"W X 78"D
