30000/50000 KVA, Pri 115000Y/66395, Sec 13800 D, 1999, GE PROLEC, COPPER
GENERATOR STEP-UP TRANSFORMER
Product Number:
040702
Full Product Description
JVT-3610
ONE (1) 30/40/50 MVA GE PROLEC GENERATOR STEP-UP TRANSFORMER, 3 PHASE,
60 HERTZ, CLASS OA/FA/FA, 65 DEGREE C RISE, 9.840% IMPEDANCE,
COPPER WINDINGS, 6 X 600:5 HV MRCT'S C-800, 3 X 1200:5 HV MRCT'S
C-800, 3 X 3000:5 LV MRCT'S C-800, 1 X 600:5 HV NEUTRAL CT C-800,
1 X 3000:5 LV AUX. MRCT C-50, HV TOP, LV SIDE, MFG. 1999
HIGH VOLTAGE: 115000Y/66395 BIL: 550 KV
LOW VOLTAGE: 13800 DELTA BIL: 110 KV
TAPS: 120750-117880-115000-112130-109250
TOTAL WEIGHT: 148,958 LBS.
CORE & COILS: 69,044 LBS.
TANK & FIT.: 37,961 LBS.
LIQUID: 41,953 LBS. (5,585 GALS.)
DIMENSIONS: 207 15/16"H X 146 1/2" W X 256 3/8"L
SHIPPING: 154 1/2"H X 126 1/16"W X 187 1/4"L
ONE (1) 30/40/50 MVA GE PROLEC GENERATOR STEP-UP TRANSFORMER, 3 PHASE,
60 HERTZ, CLASS OA/FA/FA, 65 DEGREE C RISE, 9.840% IMPEDANCE,
COPPER WINDINGS, 6 X 600:5 HV MRCT'S C-800, 3 X 1200:5 HV MRCT'S
C-800, 3 X 3000:5 LV MRCT'S C-800, 1 X 600:5 HV NEUTRAL CT C-800,
1 X 3000:5 LV AUX. MRCT C-50, HV TOP, LV SIDE, MFG. 1999
HIGH VOLTAGE: 115000Y/66395 BIL: 550 KV
LOW VOLTAGE: 13800 DELTA BIL: 110 KV
TAPS: 120750-117880-115000-112130-109250
TOTAL WEIGHT: 148,958 LBS.
CORE & COILS: 69,044 LBS.
TANK & FIT.: 37,961 LBS.
LIQUID: 41,953 LBS. (5,585 GALS.)
DIMENSIONS: 207 15/16"H X 146 1/2" W X 256 3/8"L
SHIPPING: 154 1/2"H X 126 1/16"W X 187 1/4"L
