30000/50000 KVA, Pri 230000Y/132791, Sec 13800 D, FERRANTI PACKARD, HV LTC
TRANSFORMER WITH HIGH VOLTAGE LOAD TAP CHANGING
Product Number:
040232
Full Product Description
JVT-3557:
ONE (1) 30/40/50 MVA FERRANTI-PACKARD TRANSFORMER
3 PHASE, 60 HERTZ, CLASS ONAN/ONAF/ONAF, 65 DEG. C
RISE, 9.74% IMPEDANCE, COPPER WINDINGS, TOP MOUNTED HV BUSHINGS,
SIDE MOUNTED LV BUSHINGS IN ATC, LIGHTNING ARRESTERS, 3 X HV MRCT'S
(1200:5, C800), 1 X LV MRCT (600:5, C200), NEUTRAL COV., MFG. 1999,
S/N CL 19169-10102
HIGH VOLTAGE: 230000Y/132791 BIL: 1050 KV
LOW VOLTAGE: 13800 DELTA BIL: 110 KV
HV LTC: 184000 TO 253000 IN 25 STEPS
TOTAL WEIGHT: 102,758 KG.
TOTAL FLUID: 43,017 LITERS
