10000/14000 KVA, Pri 26400 D, Sec 13200Y/7620, GENERAL ELECTRIC, LOAD TAP CHANGE
LOAD TAP CHANGING TRANSFORMER
Product Number:
038128
Full Product Description
T-5687:
ONE (1) 10/12.5/14 MVA GENERAL ELECTRIC LOAD TAP CHANGING TRANSFORMER,
3 PHASE, 60 HERTZ, CLASS OA/FA, 55/65 DEG. C RISE, 6.56% IMPEDANCE,
HV IN AIR TERMINAL CHAMBER, LV THROAT, FANS AND CONTROLS, FIXED
RADIATORS
HIGH VOLTAGE: 26400 DELTA BIL: 200 KV
LOW VOLTAGE: 13200Y/7620 BIL: 110 KV
TAPS: 27800-27100-26400-25700-25000
LV TAPS: 14500 TO 11800
TOTAL WEIGHT: 51,900 LBS.
CORE & COILS: 26,800 LBS.
TANK & FIT.: 12,700 LBS.
TANK OIL: 11,300 LBS. (1,520 GALS.)
LTC OIL: 1,100 LBS. (150 GALS.)
SHIPPING DIMS: 138.5"H x 119"W x 158"L
