12000/22400 KVA, Pri 34400 D, Sec 4160Y/2400, GENERAL ELECTRIC, SUBSTATION
SUBSTATION TRANSFORMER
Product Number:
036884
Full Product Description
ONE (1) 12/16/22.4 MVA GENERAL ELECTRIC SUBSTATION TRANSFORMER, 3 PHASE,
60 HERTZ, CLASS OA/FA/FOA, 55/65 DEG. C RISE, 7.7% IMPEDANCE
HIGH VOLTAGE: 34400 DELTA BIL: 200 KV
LOW VOLTAGE: 4160Y/2400 BIL: 75 KV
TAPS: +/- 2-1/2%
TOTAL WEIGHT: 54,550 LBS.
CORE & COILS: 24,300 LBS.
TANK & FIT.: 17,200 LBS.
MAIN TANK OIL: 9,800 LBS. (1,315 GALS.)
RADIATOR OIL: 3,250 LBS. (435 GALS.)
DIMENSIONS: 185.5"H X 137.5"W X 145"D
SHIPPING: 147"H X 106"W X 138"D
60 HERTZ, CLASS OA/FA/FOA, 55/65 DEG. C RISE, 7.7% IMPEDANCE
HIGH VOLTAGE: 34400 DELTA BIL: 200 KV
LOW VOLTAGE: 4160Y/2400 BIL: 75 KV
TAPS: +/- 2-1/2%
TOTAL WEIGHT: 54,550 LBS.
CORE & COILS: 24,300 LBS.
TANK & FIT.: 17,200 LBS.
MAIN TANK OIL: 9,800 LBS. (1,315 GALS.)
RADIATOR OIL: 3,250 LBS. (435 GALS.)
DIMENSIONS: 185.5"H X 137.5"W X 145"D
SHIPPING: 147"H X 106"W X 138"D
