3750/4687 KVA, Pri 22900 D, Sec 4160Y/2400, GENERAL ELECTRIC, SUBSTATION
SUBSTATION TRANSFORMER
Product Number:
036121
Full Product Description
T-3294
ONE (1) 3750/4687 KVA GENERAL ELECTRIC SUBSTATION TRANSFORMER, 3 PHASE, 60
HERTZ, CLASS OA/FA, 65 DEG. C RISE, 6.39% IMPEDANCE, ALUMINUM
WINDINGS, HV AND LV THROAT IN CONNECTION BOXES, S/N H881185B
HIGH VOLTAGE: 22900 DELTA BIL: 150 KV
LOW VOLTAGE: 4160Y/2400 BIL: 75 KV
NEUTRAL: BIL: 75 KV
TAPS: 24100-23500-22900-22300-21700
TOTAL WEIGHT: 17,230 LBS.
CORE & COILS: 8,250 LBS.
TANK & FIT.: 4,580 LBS.
OIL: 4,400 LBS. (590 GALS.)
DIMENSIONS: 115"H X 7'8"L X 7'8"W
