300 KVA, Pri 12470 D, Sec 208Y/120, PAUWELS, PADMOUNT, DF/RF
PADMOUNT TRANSFORMER
Product Number:
034467
Full Product Description
STOCK T-3108:
ONE (1) 300 KVA PAUWELS COMPARTMENTALIZED PADMOUNT TRANSFORMER, 3 PHASE, 60
HERTZ, CLASS OA, 65 DEG. C RISE, 4.08% IMPEDANCE, DEAD FRONT, RADIAL
FEED, S/N 85015040, LIQUID TEMPERTURE GAUGE, LIQUID LEVEL GAUGE,
VACUUM PRESSURE GAUGE, HV COPPER, LV ALUMINUM
HIGH VOLTAGE: 12470 DELTA BIL: 95 KV BIL
LOW VOLTAGE: 208Y/120
TAPS: 13094-12780-12470-12160-11840
TOTAL WEIGHT: 2,415 LBS.
OIL: 89 GALS.
ONE (1) 300 KVA PAUWELS COMPARTMENTALIZED PADMOUNT TRANSFORMER, 3 PHASE, 60
HERTZ, CLASS OA, 65 DEG. C RISE, 4.08% IMPEDANCE, DEAD FRONT, RADIAL
FEED, S/N 85015040, LIQUID TEMPERTURE GAUGE, LIQUID LEVEL GAUGE,
VACUUM PRESSURE GAUGE, HV COPPER, LV ALUMINUM
HIGH VOLTAGE: 12470 DELTA BIL: 95 KV BIL
LOW VOLTAGE: 208Y/120
TAPS: 13094-12780-12470-12160-11840
TOTAL WEIGHT: 2,415 LBS.
OIL: 89 GALS.
