200/224 MVA, Pri 138000GRDY/79674, Sec 19500 D, MCGRAW-EDISON, SUBSTATION

STOCK #G-171

ONE (1) 200/224 MVA MCGRAW-EDISON GENERATOR STEP-UP TRANSFORMER, 3 PHASE, 60
HERTZ, CLASS FOA, 55/65 DEG. C, 17.1% IMPEDANCE, COPPER WINDINGS,
HV TOP, LV SIDE

HIGH VOLTAGE: 138000GRDY/79674 BIL: 550 KV
LOW VOLTAGE: 19500 DELTA BIL: 150 KV
HIGH VOLTAGE NEUTRAL: BIL: 150 KV
HV TAPS: 145000-140000-138000-135000-130000
LV TAPS: 19500-17500-16000

TOTAL WEIGHT: 341,400 LBS.
CORE & COILS: 193,900 LBS.
TANK & FITTINGS: 64,600 LBS.
MAIN TANK: 80,400 LBS., 10,720 GALLONS
COOLERS: 2,500 LBS., 330 GALLONS
SHIPPING DIMENSIONS: 184"H X 260"L X 124"D
